Quick Specs
| DATA TYPE | DMX512 (250Khz) |
| RDM | Pass Through |
| POWER | 5V / 450mA |
| DESIGN | Compact Wall Mount |
The DSR4-WM is a DMX 1×4 (1 in 4 out) splitter with RDM pass through. Front indicators show the unit power and data status including RDM. The DSR4-WM DMX Splitter (distributor, buffer, amplifier, booster) actively splits the DMX signal providing 4 separate DMX outputs. The outputs are electronically isolated from each other and each output can source up to 32 devices (DMX512 standard). Includes 5V power supply.
For improved output isolation select the chipset upgrade for TVS “Transient Voltage Suppression” chips installed (recommended if the DMX wiring is near power lines, used outdoors, and/or near water).
FEATURES INCLUDE:
- 1 In 4 Out Splitter w/ RDM Pass Through and Bypass Switch
- Engineered with quality parts and a reliable design
- Power, DMX Data, and RDM LED indicators
- Very low
